S-5 S5U Clamp

Description

The S-5-U clamp is one of our most popular and versatile clamps, fitting about 85% of the standing seam profiles manufactured in North America, including most structural and architectural profiles. It can be used on vertically oriented seams, and by rotating the clamp 90 degrees, it can also fit most horizontal seams. Its simple design, generous dimensions, and multiple hole orientations make it ideal for use with S-5!® snow retention products and other heavy-duty applications.

The S-5-U clamp's strength and versatility come from its robust design and ample size, making it suitable for S-5!® products like ColorGard, as well as other demanding applications. However, it is not recommended for horizontal seams with widths less than .65″. The S-5-U clamp includes two 3/8″ x 24 x 0.80″ round nose set screws and one M8-1.25 x 16mm Hex Flange Bolt, all made of stainless steel.

Additional Information:

S-5-U Brochure (pdf)

S-5-U Installation Guide (pdf)

S-5-U CAD Drawing (pdf)

S-5-U ColorGard Assembly (pdf)
